ad-s321/324-ii modules (discontinued)

ad-s321/324-ii modules (discontinued)

ad-s321/324-ii modules (discontinued)


    for the manufacture of digital load cells, weighing indicators, process control weighing instruments, tensile testing machine, and other weighing or force measuring occasions.

    features and specifications:

★ operatingvoltage: 24v dc ;

★  measuring range: ±15mv

★  a/d resolution:1000000

★  temperature coefficient:≤5ppm/℃(typical)

★ hardwareinterface: rs-485interface, half-duplex.

★ software protocol: setaq freeport / modbus rtu

★  dimensions(mm):rectangle:86×55×18

★ a/d conversion,digital calibration, tare, zero setting/tracking, switch-on zero setting,anti-dithering;

★  all the parameters can be set through serialinterface;

★  module addresses are availablefrom 0 to 31. modules can work through bus communication;

★ baud rate,parity bit and data output format can be set. 1200~38400bps;

★  digital filtering: standard filtering or lpf;

★ samplingspeed: 3.125~400hz;

★ storage ofthe parameters with protection against power failure;

★  operating current:≤40ma;

★ complete protection: wrong wiring protection, overvoltage protection, transient voltage suppression;

★ operating temperature range: -40℃~ 70℃; storage temperature range: -60℃~ 90℃
