b3 series checkweigher

b3 series checkweigher

b3 series checkweigher


    setaq b3 series checkweigher can checkweigh the actual weight of products under 100g with high accuracy and high speed. it check whether the packing boxes, bags and bottles are missing by weighing online, and check the amount of ointment and injection, and rejects the unqualified products directly in the production process.  this can greatly reduce the probability that the finished products are finally identified as inferior medicine due to unqualified weight variance in future quality spot checks, and that this will lead to huge economic and reputation losses of the enterprise and the relevant license holders or production responsible persons.

    setaq b3 series checkweigher is suitable for high-accuracy weight inspection of products such as rectangular package, blister board or medium bottle on medium and high-speed production lines of drugs, food and beverage.

    setaq b3 series checkweigher can not only be installed at the discharge port of the automatic packaging machine to check whether the packaging box lacks blister plate, instruction or straw, but also be inserted in the high-speed blister production line to check whether the large-size blister plate is missing or contains half grain or incomplete. it can be connected to the discharge port of other bag packing machines to check whether the weight of the packaging bag is qualified, and it can also be connected to the bottling line or the counting machine to check the weight of the medicine bottle. it can also check the weight of the product at the outlet of the ointment and injection production line.

    setaq b3 series checkweigher adopts the weight checking control module specially designed by setaq company, which ensures the high-speed, high-accuracy and reliability.

    setaq b3 series checkweigher adopts setaq digital weighing processing software, which is specially designed for the complex working conditions of high-speed weighing field. from the control software, it ensures reliable, high-speed and high-accuracy weighing, rejection and online feedback control.

    because all its intellectual property rights are owned by the setaq company, from the bottom of the digital to analog conversion, device driver control, upper computer weight software are developed by setaq alone, so, it can also be customized according to the special requirements of our clients.


structure features:

     the checkweigher is composed of feeding belt, weighing belt and rejection belt. in the process of high-speed weighing, the high-speed cylinder is used to reject the unqualified products and make them leave the belt quickly.

    the checkweigher adopts the patent of high-accuracy sensing structure of setaq company, with the accuracy of 15mg at 80 bags / min and 20mg at 300 boxes / min.

    it adopts high speed rejection cylinder, which can reject unqualified products effectively, reliably and accurately for a long time.

main parameters:

model no. scw/b302030 scw/b301508 scw/b301816
weighing range 2-100g
capacity 300pcs/min 80pcs/min 160pcs/min
highest accuracy(±3σ) ±0.020g ±0.015g ±0.018g
resolution 0.001g
weighing speed 30-120m/min 10-40m/min 30-80m/min
weighing belt dimension length 250mm 400mm 400mm
width 160mm
product dimension length ≤150mm ≤250mm ≤250mm
width ≤140mm
total length of checkweigher 1050mm 1200mm 1200mm
preset product numbers 100
height 750±50mm
power source 220vac
air source 1.0mlpa,150nl/min
checkweighing type horizontal checkweighing
suitable products rectangular medicine package or medium medicine bottle

function features:

    ★ 10 inch industrial touch panel with english interface

    ★ the whole machine is made of stainless steel.

    ★ adopts swiss habasit weighing belt and rejection belt.

    ★ load cells are made in germany.

    ★ gates synchronous belt made in usa.

    ★ famous brand electrical switch

    ★ the histogram shows the statistical distribution of checkweighing results.

    ★ the curve shows the time distribution of checkweighing results.

    ★ the window displays the checkweighing results, standard deviation and mean value of the last 20 packages.

    ★ several statistic methods: batch statistics, qualified statistics, total statistics

    ★ can preset 100 produts parameters

    ★ setaq high accuracy digital filtering algorithm.

    ★ dynamic zero tracking, including zero tracking when the device is running

    ★ can store 25000 items of checkweighing results. u disk storage.
