climbing checkweigher

climbing checkweigher

climbing checkweigher


    climbing checkweigher adopts setaq's climbing checkweighing patent. it is butted at the lower outlet of the vertical packaging machine, and its feeding belt, weighing belt and rejecting belt are butted in turn and tilted upward to climb. the weighed objects are checkweighed and rejected in the climbing process.  setaq climbing checkweigher can checkweigh granule packaging bags within 30g on line at the speed of 120 bags / min, automatically reject unqualified products, and the highest accuracy can reach 0.02g. features:

  1.  the main structure of the checkweigher adopts the incline climbing weighing patent authorized by setaq company.

  2.  the dynamic weighing unit adopts patented structure, which can weigh effectively and reliably in the process of upward climbing.

  3. adops the checkweighing control module designed by setaq company. the module, from schematic diagram, wiring diagram to circuit board, is designed by the professional team of setaq company. it is solded by the smt chip welding production line of japan yamaha owned by setaq company. at last, it has passed various harsh tests such as environmental test, safety test, electromagnetic compatibility test, etc., which can meet the long-term and effective inspection on the packaging site.

  4. adops setaq digital weighing processing software, especially for the high speed site working condition. it can realize the reliable weighing and control at high speed with high accuracy.

structure features:

    climbing checkweigher is composed of inclined upwards feeding belt, weighing belt and rejecting belt. setaq weighing ad module acquisits the weight signal and sends the weight signal to the controller for processing; after receiving the weight signal, the rejecting unit uses the air cylinder or compressed air to reject the unqualified products and make them leave the belt.

main parameters:

weighing range 1-60g
width of belts 100-160mm
product dimension width(along the belt) ≤100mm
length(perpendicular to belt)


capacity 120 bags/min
highest accuracy(±3σ) 0.001g
resolution ±0.01g
preset product numbers 100
total length of checkweigher about 1200mm
total width of checkweigher about 600mm
height 250-450mm
rated power 0.4kw
power source 220vac
air source 1mpa,150nl/min

function features:

    ★ 10 inch industrial touch panel with english interface

    ★ the whole machine is made of stainless steel.

    ★ adopts swiss habasit weighing belt and rejection belt.

    ★ load cells are made in germany.

    ★ gates synchronous belt made in usa.

    ★ famous brand electrical switch

    ★ the histogram shows the statistical distribution of checkweighing results.

    ★ the curve shows the time distribution of checkweighing results.

    ★ the window displays the checkweighing results, standard deviation and mean value of the last 20 packages.

    ★ several statistic methods: batch statistics, qualified statistics, total statistics

    ★ can preset 100 produts parameters

    ★ setaq high accuracy digital filtering algorithm.

    ★ dynamic zero tracking, including zero tracking when the device is running

    ★ can store 25000 items of checkweighing results. u disk storage.
